MB AM5 ASRock B650M-H/M.2+ je proizvod iz kategorije Matične ploče.
Superb Productivity - PCIe Gen5 (M.2)
Rock-Solid Durability - 6+1+1 Power Phase, 50A Dr.MOS for VCore
CPU - Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*
Chipset - AMD B650
Memory - Dual Channel DDR5 Memory Technology
2 x DDR5 DIMM Slots - Supports DDR5 ECC/non-ECC, un-buffered memory up to 6400+(OC)*
Specifikacije
Superb Productivity
- PCIe Gen5 (M.2)
Rock-Solid Durability
- 6+1+1 Power Phase, 50A Dr.MOS for VCore
CPU
- Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*
Chipset
- AMD B650
Memory
- Dual Channel DDR5 Memory Technology
2 x DDR5 DIMM Slots
- Supports DDR5 ECC/non-ECC, un-buffered memory up to 6400+(OC)*
Max. capacity of system memory
128GB
BIOS
- 256Mb AMI UEFI Legal BIOS with GUI support
Graphics
Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
Audio
Audio
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
LAN
- Gigabit LAN 10/100/1000 Mb/s
• Stavka
- Realtek RTL8111H
CPU:
- 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
- 2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE3)*
• Stavka
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module*
• Stavka
- 15μ Gold Contact in VGA PCIe Slot (PCIE1)
CPU:
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
• Stavka
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
- 4 x SATA3 6.0 Gb/s Connectors
RAID
- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
• Stavka
- Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*
• Stavka
* Requires additional M.2 NVMe expansion cards to support RAID 10
USB
- 1 x USB 3.2 Gen1 Type-C (Rear)
• Stavka
- 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front)
• Stavka
- 6 x USB 2.0 (2 Rear, 4 Front)
• Stavka
* All USB ports support ESD Protection
1 x CPU Fan Connector (4-pin)*
- 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
• Stavka
- 1 x 24 pin ATX Power Connector
• Stavka
- 1 x 8 pin 12V Power Connector
1 x Front Panel Audio Connector
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
• Stavka
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
• Stavka
* CPU_FAN1 supports the fan power up to 1A (12W).
• Stavka
** CHA_FAN1~3/WP support the fan power up to 2A (24W).
• Stavka
CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in use.
1 x HDMI Port
- 1 x DisplayPort 1.4
• Stavka
- 1 x USB 3.2 Gen1 Type-C Port
• Stavka
- 3 x USB 3.2 Gen1 Type-A Ports
• Stavka
- 2 x USB 2.0 Ports
• Stavka
- 1 x RJ-45 LAN Port
1 x BIOS Flashback Button
- HD Audio Jacks: Line in / Front Speaker / Microphone
Software
- ASRock Motherboard Utility (A-Tuning)
ASRock Instant Flash
*These utilities can be downloaded from ASRock Live Update & APP Shop.
2 x SATA Data Cables
- 3 x Screws for M.2 Sockets
Form Factor
- Micro ATX Form Factor: 9.6-in x 8.9-in, 24.4 cm x 22.6 cm
OS
- Microsoft Windows® 10 64-bit / 11 64-bit
Certifications
- FCC, CE
• Stavka
- ErP/EuP ready (ErP/EuP ready power supply is required)
